Breakwire - Breakwire Triggers require a criteria of (0 = Closed) or (1 = Open)
Clock - Clock Trigger criteria refers to the internal Mission Clock of the RRC4, and is expressed as the elapsed time since arming (0.1 sec increments / 0 = Armed)
Boost - This is the Stage Number during a Motor Boost/Burn Phase as defined by the System Inertial Settings (Launch or Staging)
Coast - References the Stage Number of the Coasting Phase (after Motor Boost/Burn), as defined by the System Inertial Settings
Apogee - There are (3) criteria values for Apogee Triggers: (1) = Baro Velocity, (2) = Inertial Velocity, (3) = Baro OR Inertial Velocity
Descent - Applied to the post-apogee phase of a flight as follows: (+Value = AGL ft. / -Value = ft. BELOW Apogee)
Landing - No criteria value required (0), and this event in defined in the System Setup
Custom - Defines which Custom Trigger definition (1 or 2) is applied to this Event trigger.
Breakwire - Breakwire Triggers require a criteria of (0 = Closed) or (1 = Open)
Clock - Clock Trigger criteria refers to the internal Mission Clock of the RRC4, and is expressed as the elapsed time since arming (0.1 sec increments / 0 = Armed)
Boost - This is the Stage Number during a Motor Boost/Burn Phase as defined by the System Inertial Settings (Launch or Staging)
Coast - References the Stage Number of the Coasting Phase (after Motor Boost/Burn), as defined by the System Inertial Settings
Apogee - There are (3) criteria values for Apogee Triggers: (1) = Barometric Velocity, (2) = Inertial Velocity, (3) = Barometric & Inertial Velocity confluence
Descent - Applied to the post-apogee phase of a flight as follows: (+Value = AGL ft. / -Value = ft. BELOW Apogee)
Landing - No criteria value required (0), and this event in defined in the System Setup
